Uninstalling an RPS17 PSU

You can uninstall an RPS17 PSU from the EPS4000while the device is powered on and running.

Note: While uninstalling a PSU, wear an ESD wrist strap.

Danger: For safety reasons, the ESD wrist strap should contain a series 1 megohm resistor.

Perform the following steps to uninstall an RPS17 PSU.

  1. Put on the ESD wrist strap and ground yourself by attaching the clip end to a metal surface (such as an equipment rack) to act as ground.
  2. Lift the PSU latch and gently slide the PSU out from the slot.

    Uninstalling an RPS17 PSU

    1. RPS17 PSU slots (3 populated, 1 available)
    2. Screws
    3. PSU latch
  3. Either insert a new PSU into the slot until it clicks into place, or close the slot opening with a PSU slot cover and attach the cover with four screws.
Parent topic: Installing the EPS4000
