Installing an RPS17 PSU

You can install a new RPS17 Power Supply Unit (PSU) into EPS4000 while the device is powered on and running.

Note: While installing a PSU, wear an ESD wrist strap.

Danger: For safety reasons, the ESD wrist strap should contain a series 1 megohm resistor.

Perform the following steps to install an RPS17 PSU.

  1. Put on the ESD wrist strap and ground yourself by attaching the clip end to a metal surface (such as an equipment rack) to act as ground.
  2. Remove the four screws that hold the PSU slot cover in place.

    Installing an RPS17 PSU

    1. RPS17 PSU slots (3 populated, 1 available)
    2. Screws
    Note: If you are replacing an RPS17 PSU, you must uninstall a PSU. Refer to Uninstalling an RPS17 PSU.
  3. Remove the new PSU from the protective packaging.
  4. Gently insert the PSU into the slot until it clicks into place.
Parent topic: Installing the EPS4000
