Power supplies
The devices have one standard C14 AC power supply receptacle on the rear panel of the device for an AC power cord that uses a C13 connector. In addition, there is an optional connector on some models for the power cord from an external power supply (EPS4000) that can provide DC power to the device in the event the internal power supply fails or for supplemental power for PoE or PoE+ applications.
The following figure shows an example of a typical rear panel for an ICX 7250 device.
Note: The power connector for the
EPS4000 is typically covered with a lid that is screwed on as shown in the following figure.
To ensure proper device cooling, keep the connector covered when not in use.
