Long-Reach Multimode Adapter Module

RUCKUS ICX 7150, ICX 7250, and ICX 7750 Ethernet switches require a Long-Reach Multimode (LRM) adapter module to support LRM optics connections.

The RUCKUS LRM adapter module has two 280-mm Twinax tails and two corresponding SFP+ sockets which operate independently. Power for each of the SFP+ sockets and for the adapter is provided through the Twinax connections.

The LRM adapter module requires FastIron 08.0.61 or later on the host RUCKUS ICX switches. The LRM adapter module is not field-configurable. Rather, you can apply all configuration to the host switch port. Use the show lrm-adapter ethernet command to display the status of the LRM adapter module.

LRM Adapter Module Part Numbers

The LRM adapter module is available in the models listed in the following table.

LRM Adapter Module Models

Model/Part Number Description
10G-SFPP-LRM-1-ADP 10-GbE LRM SFP+ Optic, 1-pack bundle with LRM adapter; includes a rack-mount bracket.
10G-SFPP-LRM-2-ADP 10-GbE LRM SFP+ Optic, 2-pack bundle with LRM adapter; includes rack-mount brackets.
RMK-LRM-ADP 19-inch LRM Adapter Rack Mount Shelf Kit (supports 8 units).

LRM Adapter Module

  1. Port 1
  2. Port 2
  3. Passive cable (280 mm)
  4. 10-GbE LRM cages
  5. Adapter body

The LRM adapter module ships with either one or two LRM optics (10G-SFPP-LRM) depending on the model that you purchased.

LRM Adapter Module Specifications

  • Compatible with SFP+ ports on the ICX 7150, ICX 7250, and ICX 7750
  • Two independent SFP+ sockets for LRM optics
  • Two integrated Twinax cables for power and data connectivity to the host switch
  • Each port can operate at either 1 Gbps or 10 Gbps

LEDs

On the LRM adapter module, two LEDs indicate the power status and link status of each connection.

System and Link LEDs

  1. System LED
  2. Link LEDs

System and Link Status LEDs

System Component Description
Adapter Power Status LED off: No power

Amber: Power applied, no link

Link status LEDs Steady Green: Link up

Blinking Green: Link activity

ICX Platform Support for the LRM Adapter Module

The following table provides information the ICX platform support for the LRM adapter module

ICX Platform Support for the LRM Adapter Module

Platform Total Number of Modules Supported Total Number of LRM Connections
ICX 7150-C12P 1 2
ICX 7150-24, -24F and -48 models 2 4
ICX 7150-48ZP 4 8
ICX 7250-24 and -48 models 4 8
ICX 7150-C10ZP 1 2
ICX 7150-C08P N/A N/A
ICX 7150-C08PT N/A N/A

Note: On the ICX 7750-48F, the connections must be distributed across the SFP+ ports in the following manner:
  • Maximum three LRM modules on ports 1/1/1 to 1/1/32
  • Maximum three LRM modules on ports 1/1/33 to 1/1/48

Unpacking the LRM Adapter Module

When unpacking the LRM adapter module, verify that the shipping carton contains the items in the following list. Save the shipping carton and packaging in case you need to return the shipment.

  • One LRM adapter module
  • One or two L-shaped mounting brackets (depending on the model purchased)
  • One or two 10G-SFPP-LRM optics (depending on the model purchased)
  • China-RoHS Hazardous and Toxic Substance statement
