Wall mount installation
Note: You need a #2 Phillips screwdriver, a hammer, and a drill for wall mount installation.
RUCKUS recommends that you wall mount the device with the port side down.
Complete the following steps to mount the device to a wall.
Danger: This equipment is suitable for mounting on concrete or other noncombustible surfaces
only.
- Attach the four adhesive feet to the bottom of the device.
- Using a Phillips screwdriver, attach the wall mount brackets to the sides of the device using four #6-32 sink-head screws on each side.
- Drill two holes on the wall where you want to mount the device.
- Hammer two wall mount anchors into the holes on the wall.
- Use the two wall mount screws to fasten the device to the wall mount anchors.
