Attaching the rear brackets to the front rack posts
Complete the following steps to attach the rear brackets to the front rack posts.
- Attach the right rear bracket to the right front rack post using two 10-32 x 5/8-in. screws and two retainer nuts, as shown in Attaching the rear brackets to the front rack posts. Use the upper and lower holes in the bracket.
- Attach the left rear bracket to the left front rack post using two 10-32 x 5/8-in. screws and two retainer nuts. Use the upper and lower holes in the bracket.
- Tighten all the 10-32 x 5/8-in. screws to a torque of 25 in-lb (29 cm-kg).
